Outdoor fixed Screen-T8

Energy saving
8000nits
High Stability

high Stability 、 high brightness 、 energy saving

maintaining stability is of top priority

High Stability and reliability, excellently response to all kinds of harsh environment

Applied over 10 years in the market , High Stability and reliability with various testing such as waterproof testing , salt spray testing , aging testing and seismic testing and etc.

Various pixel pitch for different application

P6.6 P8 P10,the 3 different pixel pitch to meet the needs of different viewing distances

Applications

T series apply to Sports venue, commercial square, railway station square, airport, pedestrian street, station, subway, leisure dock, exhibition hall, etc

High protection

Comprehensive waterproof design, easy to deal with all kinds of harsh environment.

More models for your more needs, please choose your favorite one...

Product Name	T6.6	T8	T10
Pixel Configuration	DIP570	DIP570	DIP570
Pixel Pitch(mm)	6.6	8	10
Pixel matrix per panel	144x144	120x120	96x96
Cabinet Dimensions(mm)	960x960x113	960x960x113	960x960x113
Transparency Rate	/	/	/
Refresh Rate(Hz)	3840	3840	3840
Drive Mode	1/6	1/5	1/4
Brightness (nits)	8000/6000	8000/6000	8000/6000
Horizontal / Vertical Viewing Angle	110/55	110/55	110/55
AC Input Power Maximum/Average	550/185 / 440/150	550/185 / 440/150	550/185 / 440/150

Common Problem

What is the pixel pitch of the Taurus T Series T8 outdoor fixed screen?

The pixel pitch of the Taurus T Series T8 outdoor fixed screen is 8mm, which refers to the distance between the centre of each LED cluster on the screen. A smaller pixel pitch generally results in higher resolution and better image quality, but also typically comes with a higher cost.

What is the maximum brightness of the Taurus T Series T8 outdoor fixed screen?

The maximum brightness of the Taurus T Series T8 outdoor fixed screen is typically around 7500 nits, which makes it suitable for use in bright outdoor environments.

Is the Taurus T Series T8 outdoor fixed screen waterproof?

Yes, the Taurus T Series T8 outdoor fixed screen is designed to be waterproof, with an IP65 rating to protect it from rain and other environmental factors.

What is the viewing angle of the Taurus T Series T8 outdoor fixed screen?

The viewing angle of the Taurus T Series T8 outdoor fixed screen is typically around 140 degrees, which means that the image can be seen clearly from a wide range of viewing positions.

What is the lifespan of the Taurus T Series T8 outdoor fixed screen?

The lifespan of the Taurus T Series T8 outdoor fixed screen can vary depending on various factors such as usage and maintenance, but it is generally expected to last for several years. With proper care and maintenance, it can provide reliable performance and consistent image quality for a long time
